A custom-size monocrystalline solar panel should begin with the product’s physical envelope, not a nominal wattage. A module can meet an electrical target and still fail because its border covers a screw boss, its cable exits into an enclosure wall, or its tolerance leaves no room for assembly.
This guide explains how product teams can prepare the dimensional and mechanical specification for a custom solar-panel RFQ. Electrical targets still matter, but the focus here is the interface between the panel and the product.
Define the Available Installation Area
Start with a controlled two-dimensional drawing or enclosure model. Mark the maximum length and width, but also identify every feature that reduces the usable installation area:
- Screw bosses, ribs, clips, and enclosure seams
- Display, antenna, sensor, and label zones
- Ventilation or drainage paths
- Curved transitions and raised surfaces
- Cable channels and connector access
- Areas that the final product may cover or shade
A simple statement such as “the panel must be 100 mm by 60 mm” is rarely enough. The supplier needs to know whether those values describe the maximum outside dimensions, the target nominal dimensions, or the available recess in the product.
Separate Total Panel Size From Active Area
The total module outline includes more than solar cells. Space may be required for edge sealing, encapsulation, cell spacing, interconnections, cable termination, mounting features, and manufacturing tolerance.
Ask the supplier to show the proposed outside outline and active-cell boundary on the same drawing. This makes the trade-off visible: a wider inactive border may support sealing or assembly needs, while a smaller border may preserve more generating area.
Do not specify an active area by subtracting an assumed universal border. The required edge construction depends on the proposed module design and manufacturing process.
Control Length, Width, and Thickness
Identify which dimensions are functionally critical. A panel fitted inside a moulded recess may need controlled length, width, corner radius, and total thickness. A surface-mounted panel may tolerate more outline variation but require tighter control of flatness or adhesive position.
Thickness should include local features, not only the main laminate. Cable soldering areas, backing plates, connection points, adhesive liners, and strain-relief parts can create a local build-up. Show the available depth at those locations.
Use Functional Dimensional Tolerances
A production drawing should state tolerances for dimensions that affect fit, sealing, alignment, cable routing, or assembly. Avoid applying an unnecessarily tight tolerance to every dimension. Extra precision can reduce manufacturing margin without improving the product.
For each critical dimension, define:
- The nominal value
- The permitted tolerance
- The reference datum or measurement points
- The measurement method where ambiguity is possible
- The functional reason for control
Also consider the tolerance stack between the panel, enclosure, adhesive, frame, gasket, and assembly fixture. A panel drawing cannot compensate for an undefined mating part.
Specify Corner Radii and Shape Constraints
Rounded corners or an application-specific outline can help a module fit the enclosure, but every shape must leave a practical region for cells, interconnections, sealing, and handling.
Mark essential geometry separately from preferred geometry. A deep notch, narrow arm, internal cut-out, or sharp transition may reduce usable cell area or create a difficult interconnection route. If a feature can be moved or simplified, the supplier may be able to propose a cleaner layout.
This article does not define the internal cell arrangement. That is a separate design review because two panels with the same outside shape can use different cell maps and electrical configurations.
Protect Edge Clearance and Keep-Out Zones
Show where cells, conductors, cable terminations, and mounting hardware must not enter. Useful keep-out zones may include:
- Edge sealing regions
- Fastener and washer clearance
- Adhesive-free pull tabs
- Connector or cable bend space
- Housing ribs or pressure points
- Areas behind opaque graphics or covers
Do not approve a cosmetic rendering without these controlled boundaries. The module should be reviewed against the actual enclosure drawing or a representative mechanical model.
Place the Cable Exit Before Freezing the Outline
The cable exit affects both the panel and the product. Specify its location, direction, cable length, conductor requirements, polarity, connector, strain relief, and permitted bend path.
A rear exit may conflict with adhesive coverage or a housing wall. An edge exit may need additional clearance and may be visible in the finished product. The drawing should identify where the cable can leave the module and where it must reach after assembly.
If the product uses a connector, provide the exact mating interface or approved part number. A physically similar connector is not enough to define fit, pinout, or polarity.
Define the Mounting Interface
The mounting method determines which areas must remain available and what the panel experiences during assembly and service.
Adhesive mounting
Identify the enclosure material, surface finish, bond area, recess depth, application pressure, and any need for a removable liner or pull tab. Test the complete panel-and-housing bond under the intended environment rather than approving an adhesive name alone.
Mechanical fastening
Provide hole diameter, position, tolerance, edge clearance, fastener head or washer envelope, and expected assembly load. The fastening system must not place uncontrolled pressure on the active cell region.
Mounting behind a window
Define the window opening, overlap, optical path, air gap, sealing method, and the parts that can cast a shadow. Confirm the complete assembly because a clear cover can still change the usable light or create reflections.
Include Flatness, Curvature, and Assembly Conditions
If the panel sits on a flat surface, specify any flatness requirement that is necessary for bonding or appearance. If it follows a curved surface, define the installed geometry and whether bending occurs once during assembly or repeatedly in use.
Thin construction does not automatically mean a panel can accept any bend radius or repeated flexing. The supplier must review the actual module stack and use condition.
Prepare a Drawing Package for the RFQ
A useful mechanical RFQ package normally contains:
| Item | What to show |
|---|---|
| Outside envelope | Maximum or nominal length, width, thickness, and outline |
| Datums | Reference edges, centre lines, and measurement points |
| Keep-outs | Mounting, sealing, shadow, and enclosure exclusion zones |
| Shape | Corner radii, notches, holes, and essential geometry |
| Cable interface | Exit point, direction, length, bend space, and connector location |
| Mounting | Adhesive area, holes, brackets, clips, or window overlap |
| Appearance | Border alignment, visible surface, and orientation requirements |
| Assembly | Mating parts, recess, pressure points, and installation sequence |
Use a revision-controlled PDF or CAD export. Add a three-dimensional model when local thickness, curvature, or cable routing is difficult to understand from a flat drawing.
Confirm the Prototype in the Real Product
The first sample should be checked in the intended enclosure or an accurate mechanical mock-up. Verify fit, gaps, alignment, thickness, cable route, connector access, adhesive coverage, mounting hardware, and visible appearance.
Record deviations against the controlled drawing. If the outline changes, confirm whether the active layout or electrical specification also needs revision. Do not treat a mechanical change as cosmetic until its effect on the module has been reviewed.
Common Specification Mistakes
Providing only a maximum rectangle
A supplier cannot see internal obstructions, cable paths, or shadow zones from two dimensions alone.
Assuming the full outline is active area
Module construction and interfaces require inactive regions.
Leaving the cable exit until late development
The exit can conflict with cells, adhesive, walls, or assembly access.
Using tight tolerances without a functional reason
Control the dimensions that affect the product and allow practical process margin elsewhere.
Approving dimensions without a physical fit check
A prototype should be installed in the real or representative product before the design is frozen.
FAQ
Can a custom solar panel be made to any dimensions?
Many sizes are possible, but feasibility depends on cell formats, inactive borders, interconnections, cable termination, material construction, and the required electrical output.
Should the panel or enclosure be designed first?
Develop them together when possible. Early coordination protects active area and reduces conflicts around mounting and cable routing.
Can a custom panel include holes or cut-outs?
Some designs can, but the supplier must review the remaining active area, edge clearance, sealing, and interconnection route.
What should be approved before production?
Approve the controlled outline, tolerances, material stack, mounting interface, cable assembly, appearance criteria, electrical requirements, and a representative sample.
Prepare the Mechanical Interface Before Requesting a Quote
A clear dimensional specification helps the supplier evaluate feasibility without guessing which features are fixed. It also makes quotations and prototypes easier to compare because every supplier is reviewing the same installation envelope and interfaces.
